Robust pressure sensor with current output for reliable measurement in industrial applications (gases and liquids). More information
Delivery to Belgium (days are avarages)
DHL Express: 1.1 workdays, € 16,94
| Connection size | G 1/2" |
| Connection Type | External thread |
| IP Rating | IP 65 |
| Output | 4...20 mA |
| Pressure range | 0...16 bar |
| Weight | 0.21 kg |
The Danfoss MBS 1700 pressure transmitter (060G6106) is designed for stable pressure measurement in more demanding industrial conditions. With a standard current output, it is suitable for integration into common control systems. The IP65-rated design with quick response is practical for applications where reliability and durability are crucial (e.g., pneumatics, hydraulics, compressor and general industrial piping).
| Measuring range | 0-16 bar (0-232 psi) |
| Output signal | 4-20 mA |
| Power supply | 9-32 VDC |
| Accuracy (typical) | ±0.5 % FS |
| Protection | IP65 |
| Medium temperature | -40...85 °C |
| Response time | max. 4 ms |
| Pressure connection | G 1/2 (EN 837), external thread |
| Electrical connection | Angle connector, Pg 9 (EN 175301-803-A) |
