Robust pressure sensor Danfoss MBS 1700 for compressors and industry, reliable measurement even in demanding operations. More information
Delivery to Belgium (days are avarages)
DHL Express: 1.1 workdays, € 16,94
| Connection size | G 1/4 |
| Connection Type | External thread |
| IP Rating | IP 65 |
| Output | 4...20 mA |
| Pressure range | 0...16 bar |
| Weight | 0.21 kg |
The Danfoss MBS 1700 pressure transmitter is a compact industrial pressure transducer designed for reliable measurement in demanding conditions, typically in compressed air applications and general automation. With its current output and robust design, it is suitable for long-term operation. The G 1/4" connection according to EN 837 and the standard angular connector facilitate both installation and maintenance.
| Pressure Range | 0-16 bar (0-232 psi) |
| Reference Pressure | Relative (gauge) |
| Output Signal | 4-20 mA |
| Power Supply | 9-32 VDC |
| Accuracy | typ. ±0.5 % FS (max. ±1 % FS) |
| Response Time | max. 4 ms |
| Overpressure | max. 96 bar |
| Pressure Connection | G 1/4" (EN 837), external |
| Electrical Connection | Angular connector, EN 175301-803-A, Pg 9 |
| Protection | IP65 |
| Medium Temperature Range | -40...85 °C |
| Ambient Temperature | -40...85 °C |
| Temperature Compensation | 0...80 °C |
