Resideo VRM20N actuator for rotary valves, 20 Nm, power supply 24 V AC/DC, control 0–10 V or 3-point. Robust design, IP54. More information
Delivery to Belgium (days are avarages)
DHL Express: 1.1 workdays, € 16,94
| IP Rating | IP 54 |
| Power Supply | 24 VDC, 24 VAC |
| Torque | 20 Nm |
| Weight | 1.41 kg |
Catalog sheet - ENG download
Download PDFThe Resideo VRM20N actuator is designed for controlling rotary valves in heating and cooling systems. It offers optional control of 0(2)–10 V, 3-point, or 2-point and provides reliable operation thanks to its robust construction.
The actuator is mounted directly onto DR/DRG/ZR/DRU/DRR/ZRK series valves and is also compatible with V6001 dampers. It features LED indication, manual control capability, and overload protection. Designed for 24 V AC/DC power supply, IP54 protection rating.
| Power Supply | 24 V AC (+15% / -20%), 50/60 Hz or 24 V DC (±10%) |
| Torque | 20 Nm |
| Control Signal | 0(2)…10 V, 3-point, 2-point |
| Rotation Angle | 90° |
| Running Time | 120 s |
| Protection Rating | IP54 |
| Insulation Class | III (EN 60730) |
| Operating Temperature | 0…60 °C |
| Water Temperature in Valve | 1…120 °C |
| Relative Humidity | 5…95%, non-condensing |
| Weight | approx. 1.35 kg |
