Actuator for controlling air dampers GEB 331.1E. More information
This product is no longer available, as it has been replaced with a new model.
View the new model| Auxiliary contact | 0...5 V |
| Control | 3" |
| Damper size | 3 m² |
| Emergency function | 0...25 mbar |
| Power Supply | 230 VAC |
| Setup time | 150 s |
| Torque | 15 Nm |
| Weight | 1.10 kg |
Datasheet download
Download PDFActuator for controlling air handling dampers. The use of the actuator is for controlling air handling dampers in HVAC and air conditioning systems. The operating range of the actuator is mechanically adjustable between 0-90 °C. The direction of rotation can be left or right (depending on electrical control). The damper position is indicated by a position indicator located on the damper shaft collar.
