Siemens QAE2130.010 immersion temperature sensor with NTC 10k element for measuring water temperature in pipes and tanks. More information
Delivery to Belgium (days are avarages)
DHL Express: 1.1 workdays, € 16,94
| Design | Submersible |
| Measurement range | -30...125 °C |
| Sensor type | NTC 10k |
| Stem length | 100 mm |
| Weight | 0.20 kg |
The Siemens QAE2130.010 immersion temperature sensor is a passive sensor with an NTC 10k element designed for measuring water temperature in pipes and tanks. It is used in heating, ventilation, and air conditioning systems for temperature control and monitoring. The sensor is suitable for regulating or limiting the flow temperature, limiting the return temperature, and regulating hot water temperature. Installation requires a protective pocket (not included); IP54 protection can be achieved using an M16 cable gland (also not included).
| Type | QAE2130.010 |
| Sensing Element | NTC 10k |
| Measuring Range (NTC) | –30...+125 °C |
| Max. Water Temperature (QAE2130.xx) | 125 °C |
| Immersion Length | 100 mm |
| Degree of Protection | IP42 (IP54 with M16 cable gland) |
| Protection Class | III |
| Electrical Connection | Screw terminals for 1 × 2.5 mm² or 2 × 1.5 mm² |
| Nominal Pressure | PN according to the protective pocket used |
