Single-stage dry-running pump Wilo Atmos GIGA-B 65/160 (2213889)

Single-stage dry-running pump Wilo Atmos GIGA-B 65/160 (2213889)

WILO
  • Product code: 2213889
  • EAN : 4062679165875
  • Manufacturer code: 2213889
  • Warranty: 2 years

The Wilo Atmos GIGA-B 65/160-2.2/4 pump is a highly efficient single-stage dry-running centrifugal pump. More information

  • Availability

    Out of stock - can be requested

  • Out of stock
List price € 2 601,50
Price excluding VAT € 1 505,00
Price with VAT 21 % € 1 821,05
+

Parameters and catalogs

Building length 240 mm
Connection Type Flange
Liquid temperature -20...140 °C
Power Supply 400 VAC
Pressure 16 bar
Pump flow rate 98 m3/h
Pump head 11.5 m
Weight 99.00 kg

Data sheet download

Download PDF

The Atmos GIGA-B 65/160-2.2/4 pump from Wilo is a highly efficient single-stage dry-running centrifugal pump designed for installation on a base plate, distinguished by its block construction and quiet, vibration-free operation. With a lantern and a firmly connected standard motor, the pump provides a forced-flushed mechanical seal independent of the direction of rotation with the option of a Cartridge design for easy seal replacement without the need to dismantle the motor. The pump impeller is designed to minimize cavitation, and all cast iron components are protected by a cataphoretic coating.

Main Features:

  • Maximum operating pressure of 16 bar.
  • Capability to pump media at temperatures up to 140 °C.
  • The IE3 motor energy class ensures high efficiency and economical operation.
  • Pipe connection on the suction side DN 80 and on the discharge side DN 65, allowing optimal adaptation to various installation conditions.
  • Nominal motor power of 2.2 kW with nominal speed of 1450 rpm, ensuring high pumping performance.
  • Pump casing and lantern made of grey cast iron with KTL coating for high corrosion resistance.

The Atmos GIGA-B 65/160-2.2/4 is an ideal solution for applications requiring high efficiency, reliability, and long-term durability in demanding operating conditions. Thanks to its robust construction and advanced technology, the pump offers long service life and minimal maintenance requirements, making it an efficient choice for a wide range of industrial and technical applications.
