Two-way servo motor valve for water and air PEVEKO SMPE 2020.12 DN20

2 variants

Compare
Watchdog
Print
Send to e-mail

Send product by e-mail:Two-way servo motor valve for water and air PEVEKO SMPE 2020.12 DN20

From email

To email

Additional message

Two-way servo motor valve for water and air PEVEKO SMPE 2020.12 DN20

Product code: 2020012SE
Manufacturer code: 2020012SE
Warranty: 2 years

Two-way servo motor valve for water and air PEVEKO SMPE 2020.*2 DN20. More information

Availability
Out of stock - can be requested
Out of stock

Parameters and catalogs

Atex	No
Connection size	3/4"
Connection Type	Internal thread
Function	Closed without voltage
Gasket	NBR
IP Rating	IP 65
Medium	0...1.6 bar
Medium Temperature	80 °C
Nominal diameter	DN 20
Power Supply	24 VAC
Pressure	2 bar
Weight	0.80 kg

Datasheet download

Download PDF

Two-way servo motor valve (directly operated). Suitable for controlling the flow of gaseous and liquid media that do not corrode the materials used. The servo motor valve is designed for heating systems. SMPE version - closed when de-energized.

Features:

two-way servo motor valve
closed when de-energized (NC)
DN 20 / internal thread
Kv 2.3 m3/h
operating pressure 0-150 kPa
suitable for gaseous and liquid media that do not corrode the materials used (body - brass, internal parts - stainless steel, seal - EPDM rubber)
medium temperature max. 100 °C
switching time max. 5s opening / 15s closing
protection class IP 44
