Universal controller Synco 700 RMU 710B-4 for use on basic to complex ventilation, air conditioning and chilled water plants. The universal controllers are designed to handle the following controlled variables: Temperature, relative/absolute humidity, pressure/differential pressure, airflow, indoor air quality and enthalpy.

Functions:

• with yearly timeswitch
• 5 different ventilation/air conditioning plants preprogrammed
• freely configurable controller, for optimum adaptation to the relevant type of plant
• easy to expand with modules
• menu-driven operation via separate operator unit (plug-in type or detached)
• Konnex bus connection for operation and process information

Number of inputs/outputs:

• universal inputs: 8x
• continuous outputs: 3x
• relay outputs: 4x
• number of control loops: 2x

Refer to the enclosed datasheet for setup details and other specifications.
