Honeywell M7410C1007 Control Valve Actuator, 180N, 24VAC, 1.5m Cable

Product code: M7410C1007
EAN : 4024627230264
Manufacturer code: M7410C1007
Warranty: 5 years

The control actuator with 3-point control is suitable for zone regulation with a stroke of 6.5 mm and a force of 180 N. More information

Availability
Out of stock - can be requested
Out of stock

Parameters and catalogs

Cable length	1.5 m
Control	3"
Emergency function	0...25 mbar
IP Rating	IP 43
Lift	6.5 mm
Lifting force	180 N
Power Supply	24 VAC
Weight	0.23 kg

Catalog sheet download

Download PDF

The electric linear actuator with 3-point control is suitable for regulation with a stroke of 6.5 mm and a force of 180 N. They are applicable in fan-coil and induction units, for zone control, and are also suitable for heaters and coolers.

The actuator can be connected to Honeywell controllers, which monitor the exact position of the valve thanks to a pulse counter. These move the actuator from one position to another, so the actuator does not require limit switches or a feedback potentiometer.

Features:

Position display using a red plastic indicator
Medium temperature 120 °C
Protection class IP 43
Power supply voltage 24 VAC
Force on the stem 180 N
Stroke 6.5 mm
Input signal 3-point
Running time 2.5 min
Approved according to DIN EN 14597 in combination with suitable Honeywell valves
Cable 1.5 m

for valve series: V5822/23, V5832/33
