VESSEL-BOOST-60L-G1” is a membrane horizontal pressure vessel designed for efficient pressure boosting in water systems. With its replaceable EPDM membrane and steel body, it is ideal for use in potable, utility, or rainwater supply systems. ACS and WRAS certifications confirm its suitability for contact with drinking water, ensuring safety and reliability. The tank is suitable for both horizontal and vertical installation and is designed to maintain constant pressure in the water network.

Key Features:

• Horizontal design hxL 430x670 mm
• Suitable for pressure boosting according to TrinkwV 2001 with pump protection at low flow
• ACS and WRAS certification for use with drinking water, compliance with EN 13831
• EPDM membrane material and steel body for maximum durability
• Operating pressure 10, 16, or 25 bar, temperature range from 0 °C to 70 °C
• Tank surface with epoxy polyester in Wilo colour (PANTONE 334U)

Technical Specifications:

• Minimum and maximum medium temperature: 0 °C to 70 °C, with ambient temperature up to 40 °C
• G 1" piping for easy connection
• Delivery includes membrane pressure vessel, EC declaration of conformity, and installation and operation manual

VESSEL-BOOST-60L-G1” is an excellent choice for those seeking a reliable and safe solution for pressure boosting in their water systems. With its robust construction and high operating pressure, it provides consistent performance and is ready to meet the demands of modern water systems.
