Pressure sensor for liquids Siemens QBE 9210-P16 (QBE9210-P16)

Pressure sensor for liquids Siemens QBE 9210-P16 (QBE9210-P16)

Pressure sensor for liquids Siemens QBE 9210-P16 (QBE9210-P16)

SIEMENS
  • Product code: QBE9210-P16
  • Manufacturer code: QBE9210-P16
  • Warranty: 2 years

Siemens QBE 9210-P16 pressure sensor for liquids. More information

  • Availability

    Out of stock - can be requested

  • Out of stock
List price € 198,92
Price excluding VAT € 123,30
Price with VAT 21 % € 149,19
− +

Trustpilot

Parameters and catalogs

Connection size DN 8
Connection Type External thread
IP Rating IP 65
Output 4...20 mA
Pressure range 0...16 bar
Weight 0.80 kg

Catalog sheet download

Download PDF

The pressure sensor for liquids measures static or dynamic overpressure in heating systems or district heating systems. Piezoresistive measurement principle with an output signal of 0-10VDC. Pressure measurement is not affected by temperature changes.

Features:

  • External thread G 1/4"
  • Range 0...16 bar
  • Supply voltage 8...32 VDC
  • Protection rating IP 65
  • Operating temperature -25...85 °C
  • Temperature stability
  • No mechanical wear or surface changes
  • Maintenance-free
  • Excellent EMC characteristics
