The Wilo Stratos PICO 25/0.5-6 N pump is a highly efficient solution for heating and air conditioning systems, offering excellent energy savings of up to 90% compared to non-regulated pumps. Thanks to advanced technology with electronically commutated motors and integrated power regulation, the pump ensures stepless control according to the current system demand. A synchronous motor resistant to blockage allows smooth and reliable operation in a temperature range from -10 °C to +110 °C.

Key Features:

• Maximum delivery head: 63 m
• Maximum pumping capacity: 37 m³/h
• Energy efficiency: Energy Efficiency Index (EEI) ≤ 0.18
• Speed range: 700 - 4200 1/min
• Connection: G 1½ on both suction and discharge sides
• Construction length 180 mm

Additional Specifications:

• Protection class: IPX4D ensuring protection against splashing water
• Materials: Stainless steel for the pump casing and shaft, PP-GF40 for the impeller
• Regulation functions: Dynamic Adapt Plus for automatic performance adjustment, variable and constant differential pressure

The pump is equipped with a graphic colour display for easy operation and monitoring, supporting hydraulic balancing with the Wilo-Assistant application. It is the ideal choice for efficient and reliable operation in modern heating and cooling systems.

• The silver colour in the main photo is used for illustration of the stainless steel design only.
