Universal controller Synco 700 RMU 710B-4 for use on basic to complex ventilation, air conditioning and cold water plants and primary air handling featuring communicative room thermostats. The universal controllers are designed to handle the following controlled variables: Temperature, relative/absolute humidity, pressure/differential pressure, airflow, indoor air quality and enthalpy.

Features:

• yearly time switch with automatic summer-/wintertime changeover.
• 5 different ventilation/air conditioning technologies pre-programmed
• freely configurable controller for optimal adaptation to the respective technology
• easy to expand with modules
• menu-operation control via separate control unit (plug-in type or separate)
• connect Konnex communication for controlling and processing information

Number of inputs/outputs:

• universal inputs: 6x
• continuous outputs: 2x
• relay outputs: 2x
• number of control loops: 1x

Refer to the enclosed datasheet for setup details and other specifications.
